Scaffolding Pipe Thread Cutting Machine

Specifications

Industrial Machinery Corporation is recognized as one of the top ten scaffolding pipe thread cutting machine manufacturers in India. We have a decade old experience in manufacturing scaffolding pipe thread cutting machine which have 3 rollers [HU-3R rolling machine] which operates hydraulically. The scaffolding pipe thread cutting machine manufactured by us at our manufacturing unit based at Ludhiana has been recognized globally and the credit goes to the technicians working with us who makes sure on every step that the raw material used in manufacturing process is of finest quality, latest technology is used, no negotiation is made to set its meticulousness. This is the cause why our machines are highly valued by our clients straddling across the globe. Our scaffolding pipe thread cutting machine has passed all the quality assessment tests from the masters of the trade and given full marks by the market who is driven by latest technology every time. The concentricity of our scaffolding pipe thread cutting machine gives a force of 120 degrees which ensures firmness of the piece every time which further make sure that the exactitude of the result is 100 percent on every occasion. Our scaffolding pipe thread cutting manufactured and supplied by us are contented working on rolling pipes, lapping work, high-precision threading and for mass production of scaffolding pipe jack and solid jacks’ screws etc.

The scaffolding pipe thread cutting machine is used for cutting external threads on pipes by following the theory of chasing method. This machine uses HSS tangential chasers as cutters and in chasing method the pipe remains stationary whereas the die head rotates. Following are the types of threads that can be cut using the scaffolding pipe thread cutting machine but the type of thread cutting depends on the type of chaser the operator is using.

• Matric

• BSP

• BSPT

• NPT

• UNF

• UNC

• BSW

• Acme Threads

• B.S.F

Following are the parts of a scaffolding pipe thread cutting machine.

• Base Head Stock

• Saddle

• Bed or Pillar Type

• Clamping Vice

• Die Head.

Head stock is a heavy duty geared head box made up using best quality cast iron. This is fitted to give support to spindle bearings and has three extra heavy duty bearings.

Bed is a type of platform fixed on two pillars made of finest quality steel. The bed is made up of duly finished hard chrome plated steel.??

Saddle is fitted on two steel pillars very precisely to make sure that that the head stock alignment runs very accurately and precisely.

Apron is used to give movement to the saddle and the gears fixed in the apron are all made up of premium quality steel.

Vice jaws are made of steel drawn from best resources and are fitted on the saddle. Vice jaws are well-aligned with the head stock and are heat treated. The movements of these vice jaws are controlled by the screw present on the saddle.

Following are the ranges of scaffolding pipe thread cutting machine manufactured at industrial machine corporation

• 1/4" to 1" do/-

• 3/8" to 1.12" do/-

• 1/2" to 2.1/2" do/-

 Scaffolding Pipe Threading Machine

Scaffolding Pipe Threading Machine Tangential Chaser

IMC Tangential Chasers are manufactured from imported High Speed Steel which must pass exacting metallurgical standard. Experienced heat treatment with the automatic imported heat treatment plant and imported Testing equipments, assures that they will perform satisfactorily in service and produce quality threads within the tolerance for which they ware intended.

IMC Chaser are interchangeable. If one Pc. Of a chaser, the set is damaged & is beyond use. The same No. pc. The other chaser set lying in stock may be used and there will not be any difference in threading performance and the damaged set can be replaced without the necessity of replacing the entire set.
