Thread Rolling Machine
Thread Rolling Machine Thread Rolling Machine

Industrial Machinery Corporation was started in 2001 and since then we have been working with full dedication and enthusiasm to manufacture high-quality industrial machines. When it comes of scaffolding pipe thread rolling machine, we have gained an expertise in manufacturing them. We have a full fledge manufacturing unit at Ludhiana where we give our full technical and mechanical knowledge to manufacture best quality scaffolding pipe thread rolling machines. Our research wing here at Ludhiana is constantly engaged in researching on new technologies and tools to improve our machines towards a better side. Our technical team always strives to upgrade our products with the latest available technologies at economical prices. We use the latest software to design our machines. At industrial machinery corporation, we are relentlessly engaged in valuing the requirements of the customers and deliver the machines as per their requirements. we have a marvelous product known as the scaffolding pipe thread rolling machine which has over the time, surpassed all the quality-related tests and checks.

VIEW SPECIFICATIONS

Available Options


Specifications

Industrial Machinery Corporation was started in 2001 and since then we have been working with full dedication and enthusiasm to manufacture high-quality industrial machines. When it comes of scaffolding pipe thread rolling machine, we have gained an expertise in manufacturing them. We have a full fledge manufacturing unit at Ludhiana where we give our full technical and mechanical knowledge to manufacture best quality scaffolding pipe thread rolling machines. Our research wing here at Ludhiana is constantly engaged in researching on new technologies and tools to improve our machines towards a better side. Our technical team always strives to upgrade our products with the latest available technologies at economical prices. We use the latest software to design our machines. At industrial machinery corporation, we are relentlessly engaged in valuing the requirements of the customers and deliver the machines as per their requirements. we have a marvelous product known as the scaffolding pipe thread rolling machine which has over the time, surpassed all the quality-related tests and checks.

The raw material used to fabricate this scaffolding pipe thread rolling machine is twofold checked for its quality and only the best quality raw material is allowed to be used in the production process of our scaffolding pipe thread rolling machine. Our scaffolding pipe thread rolling machine is made in such a way that it gives 100 percent precise and accurate results even after working for long hours. This machine is capable of working on rolling pipes, lapping work, high-precision threading and for mass production of scaffolding pipe jack and solid jacks’ screws etc.

This scaffolding pipe thread rolling machine is used to cut external threads on pipe and this machine uses the chasing method to perform this operation. In this method of chasing, the pipe stays stationary at one place while the die head rotates to produce precise and finest rolls. HSS tangential chasers are used as cutters in our scaffolding pipe thread rolling machine and it can produce a variety of threads but mostly this range would depend upon which type of chaser in being used on this machine. Following are the types of cuts that a scaffolding pipe thread rolling machine can generate.

    Matric
  • BSP
  • BSPT
  • NPT
  • UNF
  • UNC
  • BSW
  • Acme Threads
  • B.S.F

Following are the parts of a scaffolding pipe thread cutting machine.

    Base Head Stock
  • Saddle
  • Bed or Pillar Type
  • Clamping Vice
  • Die Head.

Head stock: it is basically a geared head-box made from supreme quality casting which gives support to spindle bearing.

The bed: bed is a platform resting on two pillars which are made of nicely treated steel and are duly hard chrome plated.

Saddle: saddle is installed on two steel rods very accurately. Its main task is to precisely and effortlessly move the head stock alignment.

Apron: the apron mobilizes the saddle on the steel rack and pinion fixtures. The gears of an apron are made using finest stainless steel.

Vice jaws: the vice jaw is made up of alloyed stainless steel and a finely aligned and installed on the saddle. Vice jaws are kept under direction using a screw on the saddle and vice jaws are heat treated.

Specifications:
Model   IMC-3R-25 IMC-3R-50IMC-3R-75
Work RangeOut Side Diameter Thread Length in Feed Thread Length Through Feed

(8-25 MM) (1/2"- 1")(38 MM) (1.1/2") (Indefinite) (Indefinite)

(25-50 MM) (1"- 2")(50 MM)(2") (Indefinite)(Indefinite)

(32-75 MM) (1.1/4"- 3") (75 MM) (3") (Indefinite) (Indefinite)
Roll DiesMax. Out Side Dia. Max. Inside Dia Spindle Box140 60 40140 60 40170 80 54
MotorFor Roll Spindle3 H.P.3 H.P.7.5 H.P.
3 Phase ACFor Hydraulic System1 H.P.1 H.P.3 H.P.
Coolant Pump0.1 H.P.0.1 H.P.0.1 H.P.




Thread Rolling Dies 3 Roll Type                                                             Thread Rolling Dies 2 Roll Type

IMC Thread rolls are used on thread rolling machine. These rolls come in the set of two and three pieces manufactured from D2,D3 and M2 Material to suit any type of machine. For any specification of thread such as ISO Metric Din Whiteworth America, Trapozodical, Acme etc
